Pomoćni sklopnik CECA0.04-230V-50/60Hz 004642394 Zastarjelo

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

Specifikacije

Šifra proizvoda:
004642394
Opis:
*CECA0.04-230V-50/60Hz
Ime razreda:
Pomoćni sklopnik
Nazivni napon upravljačkog kruga Uc (V AC): 230:
230V
Nazivna frekvencija (Hz):
50Hz/60Hz
Broj pomoćnih NC kontakata:
4
Funkcija:
Pomoćni kontaktori

Dokumenti

Proizvod

Eticode težina
0.188  kg
Carinska tarifa
85364900
logis_net_width
46  mm
logis_net_height
58  mm
logis_net_depth
52  mm

Transportno pakiranje

Količina
1
EAN
7890355552636
Težina
0.194  kg
Broj paleta
4000
Klasifikacija
EC000196
Ime razreda
Contactor relay
Rated control supply voltage AC 50 Hz
230…230V
Rated control supply voltage AC 60 Hz
230…230V
Voltage type for actuating
AC
Rated operation current Ie, 400 V
10A
Connection type auxiliary circuit
Screw connection
Number of auxiliary contacts as normally closed contact
4
ETIM Clasifikacija – Verzija 7.0

Slike i dijagrami

004642394 Aux.contactor, *CECA0.04-230V-50/60Hz ETICON Miniature contactors Miniature contactor relay Miniature contactor relay CECA0 CECA0 Contactors ETICON Miniature and auxilary contactors and acessories Miniature and auxilary contactors *CECA0.04-230V-5 Function Auxiliary contactors Number of auxiliary NC contacts 4 Number of NC contacts 0 Number of poles 4 Catalogue Group Accessories CEC Rated Frequency 50Hz 60HZHz Number of auxiliary NO contacts 0 Number of NO contacts 0 Rated AC control circuit voltage Uc 230VV
