Instalacijski prekidač ETIMAT P10-QC 2p B1,6 001906203
Specifikacije
- Šifra proizvoda:
- 001906203
- Opis:
- ETIMAT P10-QC 2p B1,6
- Ime razreda:
- Instalacijski prekidač
- Nazivna struja (A):
- 1,6
- Karakteristika okidanja:
- B
- Broj polova:
- 2
- Nazivna prekidna moć (kA):
- 10
- Tip napona:
- AC
- Nazivni napon (V):
- 415
- Nazivna frekvencija (Hz):
- 50/60
- Nazivni impulsni napon Uimp (kV):
- 6
- Nazivni poprečni presjek:
- 1…4
- Standardi:
- 60898-1, 60947-2
- Funkcija:
- Instalacijski prekidači
Dokumenti
Logistički podaci
Proizvod
- Eticode težina
- 249 g
- Carinska tarifa
- 85362010
ETIM Clasifikacija
- Klasifikacija
- EC000042
- Ime razreda
- Miniature circuit breaker (MCB)
- Release characteristic
- B
- Number of poles (total)
- 2
- Number of protected poles
- 2
- Rated current
- 1,6A
- Rated voltage
- 415V
- Rated insulation voltage Ui
- 500V
- Rated impulse withstand voltage Uimp
- 6kV
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
- 10kA
- Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
- 10kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
- 10kA
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
- 10kA
- Voltage type
- AC
- Frequency
- 50…60Hz
- Current limiting class
- 3
- Suitable for flush-mounted installation
- Da
- Concurrently switching neutral conductor
- Da
- Over voltage category
- 3
- Pollution degree
- 2
- Additional equipment possible
- Ne
- Width in number of modular spacings
- 2
- Built-in depth
- 70mm
- Degree of protection (IP)
- IP20
- Ambient temperature during operating
- -60…70°C
- Connectable conductor cross section multi-wired
- 1…4mm²
- Connectable conductor cross section solid-core
- 1…4mm²
