MOD. M T2 PV 300/20 Odvodnik prenapona

ETI kod:: 002440737
Funkcija:: SPD Modul
Za upotrebu sa:: ETITEC M T2 PV
Tip struje:: DC
In (8/20):: 20 kA

Proizvod

Težina: 0,061 kg
Net width: 18 mm
Net height: 45 mm
Net depth: 64,14 mm
Stock unit of measure: pcs

Osnovno pakiranje

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895966319
Basic packaging weight: 0,068 kg
Basic Packaging Dimensions Height: 72 mm
Basic Packaging Dimensions Width: 24 mm
Basic Packaging Dimensions Depth: 50 mm
Basic packaging volume: 0,086 dm³

Transportno pakiranje

Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838895966326
Transport packaging weight: 1,713 kg
Transport Packaging Dimensions Height: 83 mm
Transport Packaging Dimensions Width: 305 mm
Transport Packaging Dimensions Depth: 116 mm
Transport packaging volume: 2,937 dm³
Pallet quantity: 8.160 pcs
Customs tariff: 85363090

Max. discharge surge current (8/20): 50 kA
Max. continuous voltage DC: 300 V
Degree of protection (IP): IP20
Mounting method: On basic element
Construction size: 1 modular spacing
Short-circuit breaking capacity (Isccr): 11 kA
Signalling at the device: Optical
Category type 2: ✓
Nominal discharge surge current (8/20): 20 kA
System configuration DC: ✓

ETIM klasifikacija – verzija 9.0
