MOD. M T12 PV 750/12,5 M Odvodnik prenapona

ETI kod:: 002440521
Funkcija:: SPD Modul
Za upotrebu sa:: ETITEC M T12 PV
Tip struje:: DC
Maksimalna odvodna struja (10/350) Iimp:: 12,5 kA
In (8/20):: 20 kA
Imax(8/20):: 60 kA

Pribor

Proizvod

Težina: 0,087 kg
Net width: 18 mm
Net height: 45 mm
Net depth: 82,14 mm
Stock unit of measure: pcs

Osnovno pakiranje

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895839538
Basic packaging weight: 0,135 kg
Basic Packaging Dimensions Height: 99 mm
Basic Packaging Dimensions Width: 24 mm
Basic Packaging Dimensions Depth: 50 mm
Basic packaging volume: 0,119 dm³

Transportno pakiranje

Transport packaging quantity: 28 pcs
EAN code for a transport packaging: 3838895839545
Transport packaging weight: 3,861 kg
Transport Packaging Dimensions Height: 109 mm
Transport Packaging Dimensions Width: 352 mm
Transport Packaging Dimensions Depth: 115 mm
Transport packaging volume: 4,412 dm³
Pallet quantity: 5.068 pcs
Customs tariff: 85363090

Max. continuous voltage DC: 750 V
Test class: Type 1 + 2
Degree of protection (IP): IP20
Mounting method: On basic element
Construction size: 1 modular spacing
Lightning impulse current (10/350 µs): 12,5 kA
Number of poles: 1
Signalling at the device: Optical
System configuration DC: ✓

ETIM klasifikacija – verzija 9.0
