002440160 Zastario

* MODUL ETITEC B 150/12,5 F Odvodnik prenapona

ETI kod:: 002440160
Funkcija:: SPD Modul
Za upotrebu sa:: ETITEC B F
Tip struje:: AC
Maksimalna odvodna struja (10/350) Iimp:: 12,5 kA
In (8/20):: 25 kA

Proizvod

Težina: 0,7 kg
Stock unit of measure: pcs

Osnovno pakiranje

Basic packaging quantity: 12 pcs
EAN code for a basic packaging: 3838895634638
Basic packaging weight: 0,9 kg
Basic packaging volume: 63 dm³

Transportno pakiranje

Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838895634645
Transport packaging weight: 1,8 kg
Transport packaging volume: 126 dm³
Pallet quantity: 6.000 pcs
Customs tariff: 85363090

System configuration TN-C: ✓
Test class: Type 1
Mounting method: On basic element
Lightning impulse current (10/350 µs): 12,5 kA
System configuration TN-S: ✓
Voltage protection level: 1 kV
System configuration TN: ✓
Number of poles: 1
System configuration TT: ✓
Signalling at the device: Optical
Max. continuous voltage AC: 150 V

ETIM klasifikacija – verzija 9.0
